C-Lite LED Linear High Bay Light | C-PHB-C-L2F Series | 12,600 Lumens | 5000K | White | 277-480V
This product has been discontinued
SKU: C-PHB-C-L2F-12L-50K-UH-WH
Replaces 6 x F32T8
12,600 Lumens
12,600 Lumens
Product Overview
Replaces 6 x F32T8. 90W C-Lite LED Linear High Bay with 12,600 delivered lumens. 4000K, white, cULus Listed, 5-year limited warranty.
WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Guides & Info
- Instruction Manual: C-PHB-C-L2F Series Download File
- Spec sheet: C-PHB-C-L2F Series Download File
- IES File: C-PHB-C-L2F-12L-50K-UH Download File
Specifications
- Applications Gymnasium, Industrial, Manufacturing, Retail, Warehouses
- Certifications cULus, Damp Locations, DLC Premium
- Color Temperature (CCT) 5000K
- Color Accuracy ≥ 80 CRI
- Dimensions 23-3/4" L x 13-1/2" W x 3-1/4" H
- Housing Steel construction, white polyester powder-coat finish
- Input Voltage 277V-480V
- Lens Material Integrated UV stabilized polycarbonate lens, designed to control the light and offer the most efficiency on the product
- Lifespan Estimated >50,000 Hours of maintenance-free operation to L70 at 25°C (77°F)
- Light Output 12,600 Lumens
- Mounting Details V-hook (included). Chain or Pendant mount supplied by others to accommodate desired length.
- Operating Temperature Maximum 104°F (40°C)
- Operating Temperature Minimum -4°F (-20°C)
- Power Consumption 90W
- Replaces 6 x F32T8
- Shipping Weight 9.41 (lbs.)
- Typical Mounting Height 15-25 feet
- warranty 5 Year
